TV70555F-859.5M Helical Tunable Bandpass Filter

TV70555F-859.5M

Product Description

Item Specify
Reference Parts TV70555F-859.5M
Acceptable 831～860M
Product Series 7H5
Stock Quantity 0

Detail Electronic Characteristic

Item Specify
Center Frequency 859.5M
Insertion Loss 5
-3 dB Bandwidth 17M
Sensitivity
(Attenuation)		 F0-(50)Mhz 64
F0+(50)Mhz 45
Return Loss > 12 dB
Impedence In / Out :50 Ω
Ripple < 1 dB

Temperature Condition

Item Specify
Operating Temperature 0C ~60C
Storage Temperature -20C ~ +70C

Mechanical Condtion

Item Specify
Size Diagram 38 X 7.6
Height 12.5mm
Input Power 1~5W
