TT67516A-850M Helical Tunable Bandpass Filter

TT67516A-850M

Product Description

Item Specify
Reference Parts TT67516A-850M
Acceptable 831～860M
Product Series 7H3
Stock Quantity 0

Detail Electronic Characteristic

Item Specify
Center Frequency 850M
Insertion Loss 3
-3 dB Bandwidth 70M
Sensitivity
(Attenuation)		 F0-(100)Mhz 26
F0+(100)Mhz 13
Return Loss > 12 dB
Impedence In / Out :50 Ω
Ripple < 1 dB

Temperature Condition

Item Specify
Operating Temperature 0°C ~ 60°C
Storage Temperature -20°C ~ +70°C

Mechanical Condtion

Item Specify
Size Diagram 22.8 X 7.6
Height 12.5mm
Input Power 1~5W
