TDL6256F-699.25M Helical Tunable Bandpass Filter
Product Description
| Item | Specify |
|---|---|
| Reference Parts | TDL6256F-699.25M |
| Acceptable | 661～700M |
| Product Series | 7H2L |
| Stock Quantity | 0 |
Detail Electronic Characteristic
| Item | Specify | |
|---|---|---|
| Center Frequency | 699.25M | |
| Insertion Loss | 5 | |
| -3 dB Bandwidth | 6M | |
| Sensitivity (Attenuation) |
F0-(20)Mhz | 19 |
| F0+(20)Mhz | 16 | |
| Return Loss | ||
| Impedence | In / Out :75 Ω | |
| Ripple | ||
Temperature Condition
| Item | Specify |
|---|---|
| Operating Temperature | 0C ~ 60C |
| Storage Temperature | -20C ~ +70C |
Mechanical Condtion
| Item | Specify |
|---|---|
| Size Diagram | 15.2 X 7.6 |
| Height | 12.5mm |
| Input Power | 1~5W |
