TD67286D-382.5M Helical Tunable Bandpass Filter

TD67286D-382.5M

Product Description

Item Specify
Reference Parts TD67286D-382.5M
Acceptable 356～400M
Product Series 7H2
Stock Quantity 0

Detail Electronic Characteristic

Item Specify
Center Frequency 382.5M
Insertion Loss 3.5
-3 dB Bandwidth 7M
Sensitivity
(Attenuation)		 F0-(30)Mhz 26
F0+(30)Mhz 20
Return Loss > 12 dB
Impedence In / Out :50 Ω
Ripple < 1 dB

Temperature Condition

Item Specify
Operating Temperature 0C ~60C
Storage Temperature -20C ~ +70C

Mechanical Condtion

Item Specify
Size Diagram 15.2 X 7.6
Height 12.5mm
Input Power 1~5W
